Spydershell™ Armor Coat

MORE THAN JUST POWDER COATING

Spydershell™ Armor Coat is a complete system that includes the state of the art in preparation, application, materials and packaging to ensure that your armor looks great for years.

Built for the Trail

+	Black semi-gloss super-durable top-coat
+	6-stage process to ensure quality, durability and great looks
+	Architectural-grade outdoor coating to withstand years of exposure to the elements
+	Salt-Spray tested 1,000 hours with less than 1/8" corrosion creep from scribe
+	Humidity resistance tested 1,000 hours with no loss of adhesion or blistering
+	Good to excellent resistance to most solvents, oils, acids and alkalies
+	5-Year warranty

As with most professional jobs, the prep work is critical.

The SpyderShell process begins with comprehensive media blasting of the Poison Spyder product, inside and out. Media blasting strips away any oils, contaminants or residues left over from the manufacturing process. It even removes laser scale and breaks the sharp edges of laser-cut parts, an area where many typical powder coat jobs first begin to fail. But most importantly it leaves a perfectly prepared surface of evenly roughed, newly exposed metal, perfect for forming the strongest possible bond between the metal and primer.

Built Different.

Prep continues with the application of 3M electrically conductive sealant, carefully applied along joints or seams where metal parts meet. This process seals off these tiny spaces to keep moisture and corrosion from occurring where the powder coat layers can not reach. The sealant itself accepts electrically charged powder coat particles just like the metal around it, and cures under heat along with the powder coat, so its invisible in the finished part.

Most common powder coated products receive a single layer of powder that has to perform all of the coating functions: adherence to the product, corrosion resistance, the desired color and texture, and long-lasting appearance despite long-term exposure to weather and UV rays. No single product can perform all of these perfectly, so premium quality coating processes use a primer layer as well as a top layer, with each engineered to perform its specific functions better than any single product is able to. SpyderShell's first coat is a zinc-rich powder coat primer, which is engineered to create the strongest bond between itself and the prepared metal surface.

Soak up the Trail

Even when the bumper is gouged on a rock, down to bare metal, it is the strength of the bond between the primer coat and the metal, that keeps moisture from penetrating and rust from forming past the edge of the scar, underneath un-damaged coating next to it. And in the event the bumper or armor does see some rock rash or a chip in the color layer from hard use, the primer layer is also black so that it won't stick out like a sore thumb if exposed. SpyderShell's top coat is of course the color layer. But more than that, we've specified an industrial, "super-durable" semi-gloss black color coat. This product was developed for architectural use, designed to withstand constant exposure to the sun and weather for years. With proper care and regular cleaning, SpyderShell will maintain its color and semi-gloss finish for years.

508456586_10161586004269353_6241321432906881650_n

Our 6-Step Process

1.	Media Blast – to remove all manufacturing residues, oils, etc., and to prepare the metal surface for maximum adhesion of primer coat
2.	Seam Seal – 3M Scotch-Weld Epoxy Adhesive to fill any un-welded seams. Powder adheres to the sealant, making sure moisture can not enter these areas and cause rust.
3.	Coat 1: Zinc Rich Primer – contains the properties for creating the best possible bond with the metal surface, and providing the best substrate for applying the color coat. Zinc rich primer helps deter corrosion. Even where the item has been scratched through to bare metal, it is the primer's job to ensure that moisture and corrosion does not spread from the exposed metal scar to under the adjacent un-scarred finish. Black primer is used so that any chips or scratches in the top coat due to wear and tear are less noticeable.
4.	Coat 2: Super-Durable Semi Gloss Smooth Black Color Coat – Architectural grade to withstand years of exposure to sunlight and weather.
5.	Carefully wrapped and packaged in specially designed protective shipping containers
6.	Protected with an unprecedented 5 Year limited warranty
